18x96 uhp grade graphite electrodes with connecting pin 9.5x 14 inch

18x96 uhp grade graphite electrodes with connecting pin 9.5x 14 inch

UHP 18X96 inch Graphite Electrode With Connecting pin 95x 14 inch (450X2400mm 4TPI)

Shanchun® Carbon – China’s leading Graphite electrodes distributor. whatsapp +8613184770996 !

Graphite electrode is one of the most important metallurgical products, mainly used as conductive material in electric arc furnace metallurgy production. UHP graphite electrodes are mainly used for steelmaking high-power and ultra-high power electric furnaces.

Graphite electrode Dimension
Nominal Diameter: 457mm (min 454mm, max 460mm)
Nominal Length: 2400 mm (+100mm,-100mm)
Nipple:  241 4TPI Long Type
Nipple Diameter: 241.3 mm (9.5")
Nipple Length: 355.6 mm (14")

Physical and Chemical Parameters of UHP450mm Graphite Electrode



Item



Unit

YB/T4090 Industry Standard

Typical Value



LSR≤

Electrode



μΩ.M

6.0

Nipple

5.0

Flexural Strength ≥

Electrode



Mpa

10.0

Nipple

18.0

Elastic Modulus ≤

Electrode



Gpa

14.0

Nipple

18.0

Bulk Density ≥

Electrode



g/cm³

1.66

Nipple

1.75

CTE ≤

Electrode



10-6/

1.5

Nipple

1.4

Ash ≤

%

0.3

Current Carrying Capacity

A

 34000-55000



Advantage
● Withstand large currents, high discharge rate
● Good dimension stability, not easy to deform
● Resistant to cracking & spalling
● High resistance to oxidation and thermal shock
● High mechanical strength, low electrical resistance
● High machining accuracy, good surface finishing
