HP 450mm Graphite Electrode

HP 450mm Graphite Electrode



HP 450mm Graphite Electrode (18 inch)
Shanchun® Carbon – China’s leading Graphite electrodes distributor. whatsapp +8615731101397 !



Graphite electrode is one of the most important metallurgical products, mainly used as conductive material in electric arc furnace metallurgy production. HP graphite electrode is mainly used for ultra high power electric arc furnaces, ladle furnace with the current density range of 18-25 A/cm2.



Graphite electrode Dimension
Nominal Diameter: 457mm (min 454mm, max 460mm)
Nominal Length: 1800/2100/2400 mm (+100mm,-100mm)
Nipple:  241 4TPI Long Type
Nipple Diameter: 241.3 mm
Nipple Length: 355.6 mm



Physical and Chemical Parameters of HP450mm Graphite Electrode





Item



Unit

YB/T4090 Industry Standard

Typical Value



LSR≤

Electrode



μΩ.M

6.5

Nipple

5.0

Flexural Strength ≥

Electrode



Mpa

10.0

Nipple

18.0

Elastic Modulus ≤

Electrode



Gpa

14.0

Nipple

18.0

Bulk Density ≥

Electrode



g/cm³

1.66

Nipple

1.75

CTE ≤

Electrode



10-6/

1.5

Nipple

1.4

Ash ≤

%

0.3

Current Carrying Capacity

A

 25000-40000





Advantage
● Withstand large currents, high discharge rate
● Good dimension stability, not easy to deform
● Resistant to cracking & spalling
● High resistance to oxidation and thermal shock
● High mechanical strength, low electrical resistance
● High machining accuracy, good surface finishing
